2. SPECIFICATION
2.1 PERFORMANCE DATA OF SWIMMING POOL HEAT PUMP UNIT
*** REFRIGERANT: R32
Heating:
Outdoor air temp: 27°C/24.3°C, Inlet water temp: 26°C
Outdoor air temp: 15°C/12°C , Inlet water temp: 26°C
Outdoor air temp: 10°C/6.8°C , Inlet water temp: 26°C
Operating range:
Ambient temperature: -15 - 43°C
Water temperature: 9-40°C
UNIT SP13 SP17 SP20
Part nr.
Heating capacity
kW
(A27/W26)
Btu/h
COP
Heating capacity
kW
(A15/W26)
Btu/h
COP
Heating capacity
(A10/W26)
kW
Btu/h
COP
Heating power input kW
Power Supply
Compressor Quantity
Compressor
Fan Number
Noise dB(A)
Water Connection mm
Water Flow Volume m3/h
Water Pressure Drop(max) kPa
Unit Net Dimensions(L/W/H) mm See the drawing of the units
Unit Ship Dimensions(L/W/H) mm See package lable
Net Weight kg see nameplate
Shipping Weight kg see package label
7031953
7031954 7031955
2.4-13.0
8189-44358
2.5-17.8 3.5-20.0
8530-60736 11942-68243
16.5-6.6
16.5-6.4 16.3-6.5
1.6-9.1
2.3-12.8
2.5-14.7
5459-31050 7848-43675 8530-50158
6.7-4.8
6.5-4.8 7.0-4.6
1.6-7.2
2.0-9.8 2.6-11.3
5459-24567
6824-33439
8872-38557
4.8-3.3
4.9-3.5 4.5-3.4
220-240V~/50Hz 220-240V~/50Hz 220-240V~/50Hz
1 1 1
rotary rotary rotary
1 1
2
37-47 40-50 41-51
50 50 50
4.1 5.2
5.6
4 5 6
2.359
3.215
3.174
See the drawing of the units
See package lable
see nameplate
see package label
7031953
7031954 7031955
2.4-13.0
8189-44358
2.5-17.8 3.5-20.0
8530-60736 11942-68243
16.5-6.6
16.5-6.4 16.3-6.5
1.6-9.1
2.3-12.8
2.5-14.7
5459-31050 7848-43675 8530-50158
6.7-4.8
6.5-4.8 7.0-4.6
1.6-7.2
2.0-9.8 2.6-11.3
5459-24567
6824-33439
8872-38557
4.8-3.3
4.9-3.5 4.5-3.4
220-240V~/50Hz 220-240V~/50Hz 220-240V~/50Hz
1 1 1
rotary rotary rotary
1 1
2
37-47 40-50 41-51
50 50 50
4.1 5.2
5.6
4 5 6
2.359
3.215
3.174
2. SPECIFICATION
2.1 PERFORMANCE DATA OF SWIMMING POOL HEAT PUMP UNIT
*** REFRIGERANT: R32
Heating:
Outdoor air temp: 27°C/24.3°C, Inlet water temp: 26°C
Outdoor air temp: 15°C/12°C , Inlet water temp: 26°C
Outdoor air temp: 10°C/6.8°C , Inlet water temp: 26°C
Operating range:
Ambient temperature: -15 - 43°C
Water temperature: 9-40°C
UNIT SP28 SP28T
Part nr. 7031956 7031957
Heating capacity
kW 6.0-27.6 7.7-28.0
(A27/W26)
Btu/h 20473-94175 26273-95540
COP 16.0-6.0 16.0-6.1
Heating capacity
kW 4.3-18.2 4.9-18.9
(A15/W26)
Btu/h 14672-62101 16719-64489
COP 6.5-4.5 6.5-4.6
Heating capacity
(A10/W26)
kW
3.1-13.7 3.6-14.2
Btu/h
10578-46746 12284-48452
COP
4.5-3.5 4.5-3.5
Heating power input kW 5.0
Power Supply 220-240V~/50Hz 380/3N~/50Hz
Compressor Quantity 1 1
Compressor rotary rotary
Fan Number 1 1
Noise dB(A) 43-53 43-53
Water Connection mm 50 50
Water Flow Volume m3/h 7.8 8.1
Water Pressure Drop(max) kPa 7 7
Unit Net Dimensions(L/W/H) mm See the drawing of the units
Unit Ship Dimensions(L/W/H) mm See package lable
Net Weight kg see nameplate
Shipping Weight kg see package label
