Nortech PD17x - Page 28

307UM0100_01 May 2016 PD17x User Manual Page 28 of 31
What application is this unit used in (short description)_______________________________________
____________________________________________________________________________________
____________________________________________________________________________________
____________________________________________________________________________________
POWER SUPPLY DETAILS:
Nominal Voltage: _______ V Minimum Voltage: _______ V Maximum Voltage: ________ V
AC or DC ? ______________ If AC then the Frequency _______ Hz
LOOP DETAILS
Channel 1
Size of loop: ____ m by ____ m
Shape of loop: _____________________
Number of Turns: _____
Size of wire used (mm
2
or AWG) _____________
Type of wire insulation _____________________
Thickness of insulation:_____________ mm
How far below the surface is the loop: ________ mm
Are there any metal objects below the loop such as concrete reinforcing, water pipes etc if yes please give details:
____________________________________________________________________________________________
____________________________________________________________________________________________
____________________________________________________________________________________________
