307UM0100_01 May 2016 PD17x User Manual Page 29 of 31
Are there any power cables below these loops (Yes/No) ____ If yes please give details:
________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
Are there any other loops in the area (Yes/No) ____ If so how many? ________ and
how close to these loops are they? ________ m
FEEDER CABLE DETAILS
Channel 1
Length of feeder cable ________ m
Size of wire used (mm
2
or AWG) _____________
(should be 1.5 mm
2
or larger)
Type of wire insulation _____________________
Thickness of insulation:_____________ mm
Type of feeder cable used (screened, armoured, multicore, etc.)
____________________________________________________________________________________________
____________________________________________________________________________________________
In the feeder cable how many twists per meter are there?____________ (should be more than 20 per metre)
Are there any other cables close to these feeder cables? (Yes/No) _____ If yes please give details:
___________________________________________________________________________________________
FEEDER CABLE and LOOP DETAILS
Channel 1
Is the loop and feeder cable one continuous piece of wire or is there a joint between the loops and the feeder?
(Yes/No) _______
Please give details:____________________________________________________________________________
____________________________________________________________________________________________
To Next Page
