15
Airflow Data
AIRFLOW (CFM)
MODEL
NUMBER
MOTOR SWITCH
SETTINGS
(0=OFF, 1=ON)
EXTERNAL STATIC PRESSURE (IN. W.C.)
0.1 0.2 0.3 0.4 0.5 0.6
1/5 2/6 3/7 4/8 CFM CFM CFM CFM CFM CFM
E7E*-0**K3
0 0 0 0 685 640 606 560 513 460
1 0 0 0 770 727 692 648 599 552
0 1 0 0 854 815 779 737 685 645
1 1 0 0 939 902 865 825 771 737
0 0 1 0 1,012 974 938 899 850 813
1 0 1 0 1,084 1,047 1,011 973 930 888
0 1 1 0 1,157 1,119 1,084 1,047 1,009 964
1 1 1 0 1,197 1,166 1,130 1,093 1,056 1,017
0 0 0 1 1,245 1,215 1,178 1,143 1,105 1,066
1 0 0 1 1,293 1,263 1,225 1,192 1,154 1,114
0 1 0 1 1,344 1,312 1,278 1,242 1,206 1,169
1 1 0 1 1,394 1,361 1,330 1,291 1,257 1,223
0 0 1 1 1,434 1,401 1,369 1,332 1,299 1,267
1 0 1 1 1,473 1,441 1,408 1,373 1,340 1,311
0 1 1 1 1,514 1,483 1,451 1,417 1,386 1,355
1 1 1 1 1,555 1,525 1,494 1,460 1,431 1,398
NOTES:
1. Motor switch settings for heating speeds use HEAT switches 1, 2, 3, and 4. For cooling speeds use COOL switches 5, 6, 7, and 8.
2. To comply with government mandated efficiency standards, two openings are required for airflows above 1600 CFM.
3. Data is shown with filter
Table 4. E7 Airflow Data
AIRFLOW (CFM)
MODEL
NUMBER
MOTOR SWITCH
SETTINGS
(0=OFF, 1=ON)
EXTERNAL STATIC PRESSURE (IN. W.C.)
25 50 75 100 125 150
1/5 2/6 3/7 4/8 CFM CFM CFM CFM CFM CFM
E7E*-0**K3
0 0 0 0 1164 1087 1030 951 872 782
1 0 0 0 1308 1235 1176 1101 1018 938
0 1 0 0 1451 1385 1324 1252 1164 1096
1 1 0 0 1595 1533 1470 1402 1310 1252
0 0 1 0 1719 1655 1594 1527 1444 1381
1 0 1 0 1842 1779 1718 1653 1580 1509
0 1 1 0 1966 1901 1842 1779 1714 1638
1 1 1 0 2034 1981 1920 1857 1794 1728
0 0 0 1 2115 2064 2001 1942 1877 1811
1 0 0 1 2197 2146 2081 2025 1961 1893
0 1 0 1 2283 2229 2171 2110 2049 1986
1 1 0 1 2368 2312 2260 2193 2136 2078
0 0 1 1 2436 2380 2326 2263 2207 2153
1 0 1 1 2503 2448 2392 2333 2277 2227
0 1 1 1 2572 2520 2465 2407 2355 2302
1 1 1 1 2642 2591 2538 2481 2431 2375
NOTES:
1. Motor switch settings for heating speeds use HEAT switches 1, 2, 3, and 4. For cooling speeds use COOL switches 5, 6, 7, and 8.
2. To comply with government mandated efficiency standards, two openings are required for airflows above 1600 CFM.
3. Data is shown with filter
