Installing the BayStack 425 Switch
23
Figure 10 IP Configuration/Setup screen
6 For a standalone switch, in the In-Band Switch IP Address field, enter the IP
address of the
switch in dotted-decimal notation.
7 For a stack configuration, in the In-Band Stack IP Address field, enter the
Stack IP address in dotted decimal notation.
Note: The In-Band Switch IP Address field allows this switch to operate
as a standalone switch. However, this field is not required for the operation
of the stack. You cannot enter the same IP address in both fields.
IP Configuration/Setup
BootP Request Mode: [ BootP Disabled ]
Configurable In Use Last BootP
------------------ -------- -----------
In-Band Stack IP Address: [ 0.0.0.0 ] 0.0.0.0 0.0.0.0
In-Band Switch IP Address: [ 134.177.224.102 ] 134.177.224.102 0.0.0.0
In-Band Subnet Mask: [ 255.255.255.0 ] 255.255.255.0 0.0.0.0
Default Gateway: [ 134.177.224.1 ] 134.177.224.1 0.0.0.0
IP Address to Ping: [ 10.30.40.1 ]
Start Ping: [ No ]
Use space bar to display choices, press <Return> or <Enter> to select choice.
Press Ctrl-R to return to previous menu. Press Ctrl-C to return to Main Menu.
