3 Reassemble the Telephone.
a. Replace the base cover and make sure that the cables lie flat.
b. Insert the four screws to secure the base.
c. Assemble the MCA to the footstand using the two screws provided.
d. Connect the cable to the 8 way jack on the base of the telephone.
e. Reconnect all cords to the telephone.
f. Replace the footstand with the two screws (if previously fitted).
g. Place the power board label on the footstand for tracking purposes.
End of Procedure
