Norton BBL547 - Page 28

28
IV. Part List Section
D. Cutting Head Gasoline Models
Item Description QTY Type
Part No
UPC NOTES
26
Cutting head BBL 20” Models Only
1
S
76124
00310004796
Cutting Head BBL 24" Models Only
1
S
232182
70184641206
27
Bearing Protection Plate 1 S
76111
00310004792
28 Bearing Blade Shaft Kit W/Hardware (2) 1 W
73418
70184655657 Set of Two (2)
Includes Mounting Hardware
29
Support Blade Shift (2) 1 S
76060
00310004767 Set of Two (2)
30
Bush Kit Nylon (2) 1 W
73220
00310004412 Set of Two (2)
31 Pulley Ø89mm X 17mm Bore 2 Groove
Blade Shaft Pulley – Key Not Included
1 S
76557
00310004888
Pulley and Set Screws
Key Not Included
32
Splash Guard Kit 1 W
73221
00310004413 Splash Guard Kit
33
Loose Collar 1 W
73281
00310004438
34
Screw ½”-20 X 1-1/2” Hex Head Cap 1 W
73217
00310004411 Blade Shaft Bolt
35
KEY 3/16x1 3/8
Key for Blade Shaft Pulley
1 W
9201081
70184649698
36
Blade Shaft Assembly 20” 1 W
76556
00310004887
Includes: Blade Shaft, Blade
Collars, and Blade Shaft Bolt.
Bearings Not Included
37 Pulley Ø81mm x 24mm Bore 2 Groove
Jackshaft pulley Output 14" Blade Guard
1 W
83859
00310007469 14” Gas Models Only
Pulley Ø58mm x 24mm Bore 2 G XPZ Belt
Jackshaft pulley Output 20" Blade Guard
1 W
76570
00310004898 20” and 24” Gas Models
Only
38 Jackshaft pulley Input
Ø112mm (4.409”) x 22mm (0.866”) Bore 2 Groove
1 W
76833
00310004964 All BBL Gas Models
39 Bearing PB JS (1) 2 W
70599
00310004011 Sold As Each
Includes Mounting Hardware
40
Jackshaft BBL 1 S
83832
00310007443
41
Jackshaft Fixation Plate 1 S
83833
00310007444
42
Motor Fixation Plate 1 S
83834
00310007445
43
Engine 13HP Honda Manual GX390UT2 1 S
123327
70184671620
Engine Only
44
Motor pulley Ø90mm (3.54”) x 1” Bore 1 W
83836
00310007446
45 Belts XPZ 1250 LW (2)
14" Blade Guard Gas Only
1 W
83837
70184683500
Set of Two (2)
14” Gas Models Only
Belts XPZ 1212 LW (2)
20" And 24” Blade Guard Gas Only
1 W
83472
70184683499 Set of Two (2)
20” and 24” Gas Models Only
46 Belts XPZ 780 LW (2)
Jackshaft Belts All Gas Models
1 W
83838
00310007448 Set of Two (2)
Jackshaft Belts
47
Belt Guard Bracket BBL 14” and 20” Gas Only 1 S
83839
00310007449
Belt Guard Bracket BBL 24” BBL Gas Only 1 S
232184
70184646032
48
Belt Guard BBL 14”, 20”, and 24” Gas Only 1 S
83840
00310007450 All Gas Models
49
Water Pump Pulley 1 S
76552
00310004883
50
Guard Jackshaft All BBL Gas 1 S
83841
00310007451
51
Jackshaft Protection Plate 1 S
83842
00310007452
52
Guard Support Plate 1 S
83843
00310007453
53
Leveling Support 1 S
76113
00310004794
54
Blade Guard 14” 1 S
76037
00310004753
Blade Guard 20” 1 S
76126
00310004797
Blade Guard 24” 1 S
232178
70184641211
Type: S = Service Part, W = Wear Part, All Parts Are Sold As Individual (each) Unless Noted Otherwise
