6
I. PREPARATION
B. Assembly
1. Remove machine from skid.
2. Remove the conveyor cart and guide-a-cut from the carton and place on the
pan.
3. Remove the drain plug from carton and place in drain opening in bottom of
pan.
4. Check the owner’s manual for wiring connection and proper electrical
connections before starting saw.
C. Assembly Conveyor Cart & Guide-a-Cut
The Block Buster Masonry saws are shipped completely assembled and ready
for use except for diamond blade, gasoline, and oil. Inspect the saw for
shipping damage. If any damage is found, contact the shipper immediately
and file a freight claim.
Norton Construction Products is not
responsible for any freight-related damages.
Remove the saw from
the pallet.
Items Included with the saw:
Item Part No UPC QTY Notes
Conveyor Cart Assembly 83777 00310007390 1
Guide-A-Cut Assembly 83892 00310007501 1
Splash Guard Assembly 75128 00310004632 1
Wrench 19 mm 70807 00310004053 1
Wrench 22mm 72143 00310004199 1
Water Pump Assembly 72305 00310004237 1 Gasoline Powered Machines Only
Pump Water Electric 214169 70184668392 1 Electric Powered Machines Only
Fit Barb Hose 1/4FPTX1/2 9602010
70184650470
1 Electric Powered Machines Only
Owner’s Manual Form BBL527-
1327 -NA-
1 Form BBL527-1327 Manual Rev 4-
2012
Diamond Bade
1 General Propose Same Diameter as
Blade Size
Do not install the blade until it is time to use the saw!
ANSI regulations prohibit the transportation of any concrete saw with
the blade installed!
