Norton BBL547 - E. Cutting Head Electric Models

31
IV. Part List Section
E. Cutting Head Electric Models
Item Description QTY Type
Part No
UPC NOTES
26
Cutting head BBL 20” Models Only 1 S
76124
00310004796
Cutting Head BBL 24" Models Only 1 S
232182
70184641206
27
Bearing Protection Plate 1 S
76111
00310004792
28 Bearing Blade Shaft Kit W/Hardware (2) 1 W
73418
70184655657 Set of Two (2)
Includes Mounting Hardware
29
Support Blade Shift (2) 1 S
76060
00310004767 Set of Two (2)
30
Bush Kit Nylon (2) 1 W
73220
00310004412 Set of Two (2)
31 Pulley Ø89mm X 17mm Bore 2 Groove
Blade Shaft Pulley – Key Not Included
1 S
76557
00310004888
Pulley and Set Screws
Key Not Included
32
Splash Guard Kit 1 W
73221
00310004413 Splash Guard Kit
33
Loose Collar 1 W
73281
00310004438
34
Screw ½”-20 X 1-1/2” Hex Head Cap 1 W
73217
00310004411 Blade Shaft Bolt
35
KEY 3/16x1 3/8
Key for Blade Shaft Pulley
1 W
9201081
70184649698
36 Blade Shaft Assembly 1 W
76556
00310004887
Includes: Blade Shaft, Blade
Collars, and Blade Shaft Bolt.
Bearings Not Included
44
Pulley Ø82mm (3.23”) x 7/8" Bore 2G XPZ
1 S
83859
00310007469 BBL 14” Electric Only
Pulley Ø62mm (2.44”) x 7/8” Bore 2G XPZ
1 S
83860
00310007470 BBL 20” Electric Only
Pulley Ø50mm (1.96”) x 7/8” Bore 2G XPZ 1 S
232186
70184641210 BBL 24” Electric Only
45 Belt XPZ 1500 LW (1) 2 W
72926
00310004360 Sold as Each (1)
BBL 14” Electric Only
Two (2) Required
Belt XPZ1480LW (2) 1 W
73282
00310004439 Set of Two (2)
BBL 20” Electric Only
Belt XPZ1850 LW (2) 1 W
232179
70184641209 Set of Two (2)
BBL 24” Electric Only
47
Belt Guard Bracket BBL 14” and 20” Electric 1 S
73298
00310004447
Belt Guard Bracket BBL 24” Electric 1 S
232180
70184641208
48
Belt Guard BBL 14” and 20” Electric Only 1 S
76129
00310004798
Belt Guard BBL 24” Electric Only 1 S
232181
70184641207
49
Water Pump Pulley 1 S
76552
00310004883
53
Leveling Support (Blade Guard Support) 1 S
76113
00310004794
54
Blade Guard 14” 1 S
76037
00310004753
Blade Guard 20” 1 S
76126
00310004797
Blade Guard 24” 1 S
232178
70184641211
55
Water Hose (1/2" x 3/4" x 48") 1 W
72411
00310004270
56
Valve Petcock 1/4MPT X1/2 1 W
72357
70184681061
57
Hose “Y” 1 W
72286
00310004233
58
Nozzle Water Kit (2) 1 W
80568
00310002235 Set of Two (2)
59
Screws Water Pump 1 S
75280
00310004671 Mechanical Pump Only
60
Water Pump PE-1 1 W
214169
70184668392 BBL Electric Only
60a
Screen Water Pump PE-1 1 W
155775
70184680196 BBL Electric Only
60b
Impeller Water Pump PE-1 1 W
155774
70184680194 BBL Electric Only
60c
Volute Water Pump PE-1 1 W
101375
70184680195 BBL Electric Only
61
Fitting Barb Hose ¼” FPT X ½ Male Barb 1 S
9602010
70184650470
Type: S = Service Part, W = Wear Part, All Parts Are Sold As Individual (each) Unless Noted Otherwise
