I. PREPARATION
D. BBL Series Masonry Saw Specifications
Dimensions/Weight
Length 41” (1041mm)
Width 26” (660mm)
Height (Electric) 54” (1372mm)
Height (Gas) 57” (1448mm)
Weight (Electric) Uncrated 440lbs (970kg)
Weight (Gas) Uncrated 460lbs (1014kg)
Electric Motor
Motor Mfg. Baldor
Motor Type TEFC, Thermal Protection
Motor RPM 3,450 RPM
Single Phase:
BBL527
BBL547
BBL5247
5 HP - 230v 60 Hz single Phase (Standard)
Run Amperage: 20.6 Amp @ 230v
Three Phase 5 Horse Power
BBL527 3PHASE
BBL547 3PHASE
BBL5247 3PHASE
5 HP - 230-460v 60Hz three Phase (Optional)
Three Phase 7-1/2 Horse Power
BBL727 3PHASE
BBL7247 3PHASE
7-1/2 HP 230-460v 60Hz three Phase
Run Amperage: 8.4 Amp @ 230v/4.2 Amp @ 480v
Three Phase 7-1/2 Horse Power 575v
BBL727 575v 3PHASE
7-1/2 HP 575v 60Hz three Phase (Optional)
Thee Phase 5 Horse Power 600v
BBL527 600v 3PHASE
5 HP - 600v 60 Hz single Phase (Optional)
Engine (Gasoline Models Only)
Engine Mfg. Honda
Spec No. GX390K1QXC9
Model GX390
Engine Type Single Cylinder 4 Cycle
Horse Power 13 hp (9.5kW) @ 3,600 rpm
Max Torque 19.5 ft-lbs (26.5 Nm, 2.7 kg-m) @ 2,500 rpm
Cooling System Air
Oil Capacity 1.1 liter (1.16 US qt)
Fuel Capacity 6.5 liter (1.79 US gal)
Fuel Type Unleaded Gasoline (86 pump octane)
Low Oil Sensor Yes
Air Filtration Four Stage Cyclone
Characteristics
Max Blade
20” (508 mm) or 14” (356 mm)
Depth of Cut 24” (610 mm) 10” (254 mm)
20” (508 mm) 8” (203 mm)
14” (356 mm) 5” (127 mm)
Arbor Bore 1” (25.4 mm)
Blade Shaft Locking Device Machined Into Flats Of Tight Collar
Blade Shaft Speed 24” 1938 rpm
20” 2400 rpm
14” 2900 rpm
Depth Control Hand Feed With Return Spring
Depth Lock Standard
Number Of V-Belts 2
Blade Guard Type All Steel Construction
Stay Level Blade Guard Yes
Fork Lift Brackets Built In
Water Pump (Gasoline Models) Mechanically Belt Driven
Water Pump (Electric Models) Electrical 115v/60Hz
