Maintenance Instruction
60
4.18 Fuel Tank Maintenance
• Stop the tractor on level ground, switch off the engine
and then remove the drain plug below the fuel tank.
Discharge the sedimented dirt at the bottom of the fuel
tank.
Figure 4-31 Fuel Tank Maintenance
• The sediment bowl of the fuel tank gathers water
and impurities. When maintaining the fuel tank, the
sedimented dirt in the sediment bowl B at the
bottom of the fuel tank should be discharged
simultaneously.
Figure 4-32 Fuel Tank Sediment Bowl
4.19 Tire Inflation Pressure
Check the tire pressure with the an air pressure guage. The tire inflation pressure is shown in the Technical
Specifications of XT Series Tractor.
NOTE: If the tire pressure is too high or too low, it will shorten the service life of the tires, influence the
tractor’s operation and potentially cause accidents.
