System Parameters To read System Parameters, follow these steps.
1. Select Read Point from the Read Status screen to display the Read Point screen
(Figure 11):
2. Press <Z>, <S0>, <Enter> to display the System Parameters screen, which
typically displays as shown in Figure 22:
Figure 22 System Parameters Screen 0
Table 15 contains descriptions of the items shown on System Parameter Screen (Figure
22):
Table 15 System Parameters
Parameter Description Set to...
SIL INH=060 Silence Inhibit timer in
seconds. Required in
Canada and some areas of
the USA.
0 – no timer; or the timer
duration in seconds.
AUTO=600 Automatic Silence timer in
seconds.
0 – no timer; or the timer
duration in seconds.
VERIFY=30 Alarm Verification timer 0 – no timer; or the timer
duration in seconds.
USA TIME Time/date display format USA TIME or EUR TIME
TERM_SUPERV=YES Terminal supervision YES – To supervise the wiring of
a terminal mode LCD-80.
NO – No Terminal mode and no
LCD-80 supervision.
LocT One of three operating
modes of a PC or terminal
connected to the control
panel (through TB2 PC/
Terminal). For a complete
list of functions, refer to the
AFP-300/AFP-400
Installation Manual.
LocT – terminal connected to
control panel and located in the
same room as the control panel.
LocM – terminal connected to
control panel but requires
password for operation.
RemT – terminal connected
through a modem for Read Status
operations only.
BLINK=Y Blink LEDs on intelligent
devices during polling (for
certain applications).
Y – blink LED; or
N – do not blink LED.
ST=4 NFPA wiring style operation
for the SLC loop
4 – Style 4 SLC loop; or
6 – both Style 6 and Style 7 SLC
loop.
ACS=N Use ACS Selection Groups
(refer to the AFP-300/
AFP-400 Installation
Manual for details).
N – No annunciator selected; or
Y – Select and display ACS
Selection Groups.
SIL INH=060 AUTO=600 VERIFY=30 USA TIME
TERM SUPERV=NO LocT BLINK=Y ST=4 ACS=N
