Notifier AM2020 Operation And Installation Manual

1010
1010
10 Voice Alarm Multiplex 15889:F2 10/01/01
22
Notes:Notes:
Notes:Notes:
Notes:
1) All the above tone/messages sequences will repeat until they have been deselected through the annunciator
control point. Priority within each group of four is from top (highest priority) to bottom (lowest priority). The
AEM-16AT must be the first expander attached to the ACM-16AT.
2) If a digitally-stored voice message fails, the AMG-1 will automatically switch to the primary evacuation tone
and will generate a trouble condition.
3) All pauses are 5 seconds long unless otherwise noted.
Table 3-2: AMG-1 Tone/Message Functions
(for AMG-1 addresses A28 through A25, AMG-X4 EPROM required)
Audio Message
Generator DIP
Switch Settings
Annunciator Control Points
on AEM-16AT Address A01
AMG-1 at Address
Tone/Voice Message Group Functions
S6 S7 S8 A28 A27 A26 A25
Off Off Off P17 P21 P25 P29 VROM A
Off Off Off P18 P22 P26 P30 VROM B
Off Off Off P19 P23 P27 P31 VRAM A
Off Off Off P20 P24 P28 P32 VRAM B
Off Off On P17 P21 P25 P29 3 Fast Whoops, Pause, VROM A
Off Off On P18 P22 P26 P30 3 Hi/Low Tones, Pause, VROM B
Off Off On P19 P23 P27 P31 3 Yeows, Pause, VRAM A
Off Off On P20 P24 P28 P32 3 Slow Whoops, Pause, VRAM B
Off On Off P17 P21 P25 P29 3 Fast Whoops, Pause, VROM A, VROM B
Off On Off P18 P22 P26 P30 3 Hi/Low Tones, Pause, VRAM A
Off On Off P19 P23 P27 P31 3 Yeows, Pause, VRAM B
Off On Off P20 P24 P28 P32 Wail
Off On On P17 P21 P25 P29 3 Slow Whoops, Pause, VROM A
Off On On P18 P22 P26 P30 3 Hi/Low Tones, Pause, VROM B
Off On On P19 P23 P27 P31 Yelp
Off On On P20 P24 P28 P32 Wail
On Off Off P17 P21 P25 P29 3 Slow Whoops, Pause, VRAM A
On Off Off P18 P22 P26 P30 3 Hi/Low Tones, Pause, VRAM B
On Off Off P19 P23 P27 P31 Yelp
On Off Off P20 P24 P28 P32 Wail
On Off On P17 P21 P25 P29 3 Slow Whoops, Pause, VROM A
On Off On P18 P22 P26 P30 3 Hi/Low Tones, Pause, VRAM A
On Off On P19 P23 P27 P31 Boston Code
On Off On P20 P24 P28 P32 Horn
On On Off P17 P21 P25 P29 California Uniform Fire Code (10s Yelp, Pause)
On On Off P18 P22 P26 P30 California Uniform Fire Code (10s Fast Whoops, Pause)
On On Off P19 P23 P27 P31 3 Hi/Low Tones, Pause, VROM A, Pause
On On Off P20 P24 P28 P32 3 Slow Whoops, Pause, VRAM A, Pause
On On On P17 P21 P25 P29 Yelp
On On On P18 P22 P26 P30 Hi/Low Tones
On On On P19 P23 P27 P31 Slow Whoop
On On On P20 P24 P28 P32 NFPA Code (Three 470 Hz Tones, 1.5s Pause)
