Viewing and Printing a Read Status Read Status Operation
An Annunciator Selection screen shows the information that will display on the ACS annunciators.
The table above contains the ACS display selections. Annunciators set to annunciator address 1 to
19 can be programmed to any one of the above selections. If t here is a UDACT, selections A-M
will be sent to Annunciator addresses 20 to 32 respectively.
An example of ACS selections in Annunciator Selection Screen 1:
Figure 4.14 Annunciator Selection Screen 1 Example
NOTE: An ACS selection marked with an asterisk (*) indicates no annunciator selection.
The figure above shows annunciator selections for addresses A1-A2 (addresses A3-A10, marked
with asterisks, are not selected).
• Annunciators set to annunciator address 1 (A1) display the status of detectors 1-64 on SLC 1
(ACS Selection Group H)
• Annunciators set to annunciator address 2 (A2) display the status of intelligent modules 1-64
on SLC-1 (ACS Selection Group C).
1 through 9 Programmable Annunciator #1 through #9
0 Programmable Annunciator #10
A 8 Systems points + Zones 1-56
B Zones 57-99, 9 F zones, 8 R zones, 4NAC
C Loop 1, Modules 1-64
D Loop 2, Modules 1-64
E Loop 1, Modules 65-128
F Loop 2, Modules 65-128
G Loop 1, Modules 129-159 & Loop 2, Modules 129-159
H Loop 1, Detectors 1-64
I Loop 2, Detectors 1-64
J Loop 1, Detectors 65-128
K Loop 2, Detectors 65-128
L Loop 1, Detectors 129-159 & Loop 2, Detectors 129-159
M Programmable for use with FireVoice NFV-25/50ZS
N 8 Systems points + Zones 1-56, used for remote station communicator (TM-4)
O 8 Systems points + Zones 1-56, used for municipal box trip output (TM-4)
P Loop 1, Modules 65-100, Loop 1, Detectors 1-14 (Detector Maintenance
Reporting)
Q Loop 2, modules 65-100, Loop 2, Detectors 1-14 (Detector Maintenance
Reporting)
R Loop 1, detectors 15-46 (Detector Maintenance Reporting)
S Loop 2, Detectors 15-46 (Detector Maintenance Reporting)
T Loop 1 Detectors 47-78 (Detector Maintenance Reporting)
U Loop 2, Detectors 47-78 (Detector Maintenance Reporting)
V Loop 1, Detectors 79-100 (Detector Maintenance Reporting)
W Loop 2, Detectors 79-100 (Detector Maintenance Reporting)
Annunciator addresses 1 to 19 can be programmed to any one of the above selections. If there is a UDACT,
selections A-M will be sent to Annunciator addresses 20 to 32 respectively.
Table 4.2 ACS Selection Groups (2 of 2)
ANNUN SELECTION: A1=H A2=C A3=* A4=*
A5=* A6=* A7=* A8=* A9=* A1-=* A11=*
