40
Note: Scroll
ring will fall
into place
when it
engages with
jaw slide teeth.
If the scroll
ring is not
falling into
place, check to
see if the jaw
slides are all
aligned
properly in the
centre.
5.
Secure the
scroll ring by
reinstalling the
circlip.
Check the
chuck
operation
smoothness to
finish the
assembly
process.
