6
English
www.novasina.com
2.2 System Architecture
The LabTouch-aw consists of modular assemblies in combination with the
unique resistive-electrolytic Novasina measurement technology, which is part
of the aw-sensor. The aw-measurement signal is electronically processed tog-
ether with the IR (infrared)sample temperature measurement and an additional
temperature monitoring in the instrument's body. Recorded data can be stored
on an external, removable SD-card. The mains are supplying the instrument
and optional external chambers.
The touch screen allows intuitive programming of the instrument as well as
easy access to the various menus.
The LabTouch-aw comprises a semi-temperature stabilization of the measu-
rement chamber which allows heating but no cooling.
For checking and adjusting the instrument, humidity standards can be used.
2.3
Instrument Overview
Front view:
The measurement cell including infrared temperature measurement is located in the inner part of the
LabTouch-aw
Button to start-up the instrument
and open chamber
Touch screen
color display
Ventilation slits
(do not block)
Data storing slot
SD card reader
