MCTRL4K User‘s Manual
7 Technical Specifications
Inputs
Port Qty Specifications
DP 1
DP1.2 standard
Max. supported resolution:3840×2160@60Hz, Max. width
and height are 3840(downward compatibility)
HDMI
1
HDMI-2.0 standard
Max. supported resolution:3840×2160@60Hz
Max. width and height are 3840 (downward compatibility)
Dual-link DVI
2
VESA standard
Max. supported resolution:3840x1080@60Hz and
3840×2160@30Hz (downward compatibility)
Outputs
Port Qty Specifications
RJ45 16 Neutrik Gigabit Ethernet port
OPT
4
Optical fiber port, single mode and double fiber, LC port,
1310mm
OPT1 is used for transferring the data of port 1-8
OPT2 is used for transferring the data of port 9-16
OPT3 is the backup channel of OPT1
OPT4 is the backup channel of OPT2
Either Gigabit Ethernet port or optical fiber port can be used
at the same time. Two types of ports cannot be used to
connect devices simultaneously.
Control
Port Qty Notes
ETHERNET 1 Control interface
USB
2
Control interface of upper computer and cascading
interface
Overall Specifications
Input Power AC 100-240V, 50/60Hz
Overall Power Consumption 30W
Operating Temperature -20~60℃
Dimensions(L×W×H) 482.6×372×89(mm)
Weight 4.6kg
