MCTRL4K User‘s Manual
-2-
Inputs
DP 1.2 DP 1.2 interface
HDMI 2.0 HDMI 2.0 interface
DUAL DVI-D1/D2 Dual-link DVI interface
Outputs
1~16 16-channel Neutrik Gigabit Ethernet outputs
OPT1~4
4-channel optical fiber outputs
OPT1 is corresponding to Ethernet port 1~8.
OPT2 is corresponding to Ethernet port 9~16.
OPT3 is the backup of OPT1. OPT4 is the backup of
OPT2.
Control
ETHERNET Control interface
USB
IN: cascade input or connecting PC;
OUT: cascading next unit.
GenLock
IN
Genlock synchronous signal, making sure the picture
on LED display is in sync with external Genlock
source.
Genlock type: Blackburst
LOOP Genlock loop output
Power
AC 100-240V ～ 50/60HZ AC power interface
Note: Type A(flat) USB interface is not allowed to be connected to control computer
directly.
