Maximum Output Power and Current (5V and 3.3V supplies are independent):
Nominal
Max Output Power
Max Output Current
Min Interruption
Ride-Through*
Vin
3.3V
5V Total 3.3V 5V ms
24Vdc
12.5W
12.5W 25W 3.75A 2.5A
2.5ms
48Vdc
17.5W
17.5W 35W 5.3A 3.5A
6.5ms
69Vac
17.5W
17.5W 35W 5.3A 3.5A
10ms
125Vdc
17.5W
17.5W 35W 5.3A 3.5A
35ms
120Vac
17.5W
17.5W 35W 5.3A 3.5A
50ms
250Vdc
17.5W
17.5W 35W 5.3A 3.5A
140ms
230Vac
12.5W
12.5W 25W 3.75A 2.5A
220ms
240Vac
12.5W
12.5W 25W 3.75A 2.5A 230ms
* M871 -V10 -S10 -H10 -A10 -P11 -P30 (all relays energized)
The +12Vdc output is derived from the 3.3Vdc output, and the -12Vdc output is derived
from the 5Vdc output. The +/- 12Vdc outputs are capable of providing up to 500mA,
however, they must be de-rated to avoid exceeding the maximum power limits of the
3.3Vdc and 5Vdc outputs respectively.
6.3.1 Environmental
Operating Temperature: -40C to 70C
Relative Humidity: 0-95% non-condensing
Installation Category: IC III (Distribution Level), Pollution Degree 2. Refer to definition
on page 9.
6.3.2 Physical
Input Connections: Removable terminal block accepts #26-12 AWG (0,15-3,3mm
2
)
wire, or terminal lugs up to 0.325" (8,25mm) wide.
Recommended minimum wire size is #18 AWG (0,5 mm
2
).
Recommended Torque Rating for the terminal block wire
fasteners is 10 In-Lbs, 1.13N-m. Precautions must be taken to
prevent shorting of lugs at the terminal block. A minimum
distance of 0.1” (2.5mm) is recommended between un-insulated
lugs to maintain insulation requirements. Standard 0.200"
(5,08mm) header socket accepts other standard terminal types.
Backplane Connections: Standard cPCI-specified power connector
