9,02/08/17,10:37:26.855,0,Hinkson_Creek_substation,DIO#0Input1,Close
10,02/08/17,10:37:26.859,0,Hinkson_Creek_substation,DIO#0Input2,0
11,02/08/17,10:37:26.863,0,Hinkson_Creek_substation,DIO#0Input3,0
12,02/08/17,10:37:26.863,0,Hinkson_Creek_substation,DIO#0Input4,0
13,02/08/17,10:37:26.863,0,Hinkson_Creek_substation,Breaker5(DIO_0Input5),0
14,02/08/17,10:37:26.876,0,Hinkson_Creek_substation,
Breaker6(DIO_0Input6),0
15,02/08/17,10:37:26.880,0,Hinkson_Creek_substation,Breaker7(DIO_0Input7),_OPEN_
16,02/08/17,10:37:26.880,0,Hinkson_Creek_substation,Breaker8(DIO_0Input8),0
17,02/08/17,10:38:09.217,0,Hinkson_Creek_substation,Breaker6(DIO_0Input6),1
18,02/08/17,10:38:09.256,0,Hinkson_Creek_substation,Breaker6(DIO_0Input6),0
19,02/08/17,10:38:09.443,0,Hinkson_Creek_substation,
Breaker6(DIO_0Input6),1
20,02/08/17,10:38:09.577,0,Hinkson_Creek_substation,Breaker6(DIO_0Input6),0
21,02/08/17,10:38:18.439,0,Hinkson_Creek_substation,Breaker5(DIO_0Input5),1
22,02/08/17,10:38:18.523,0,Hinkson_Creek_substation,Breaker5(DIO_0Input5),0
23,02/08/17,10:38:18.585,0,Hinkson_Creek_substation,Breaker5(DIO_0Input5),1
24,02/08/17,10:38:18.586,0,Hinkson_Creek_substation,Breaker
5(DIO_0Input5),0
25,02/08/17,10:38:18.588,0,Hinkson_Creek_substation,Breaker5(DIO_0Input5),1
26,02/08/17,10:38:18.590,0,Hinkson_Creek_substation,Breaker5(DIO_0Input5),0
27,02/08/17,10:38:19.455,0,Hinkson_Creek_substation,DIO#0Input2,1
28,02/08/17,10:38:19.615,0,Hinkson_Creek_substation,DIO#0Input2,0
29,02/08/17,10:38:21.369,0,Hinkson_Creek_substation,DIO#0Input2,
1
30,02/08/17,10:38:21.540,0,Hinkson_Creek_substation,DIO#0Input2,0
31,02/08/17,10:38:23.979,0,Hinkson_Creek_substation,Breaker7(DIO_0Input7),____CLOSED____
****EndofFile****
5.5 M87x File System
Files are stored in the M87x on internal drives labeled "c:" and "d:". In addition the host
module contains optional compact flash memory which is accessible as drive "e:". Both
FTP and Zmodem may be used to access any drive. Trend Recorder files are stored on
the d: drive on the host module. All other user accessible files will be stored on the c: drive
unless the unit is equipped with optional compact flash memory. In this case these files are
stored on the e: drive. The following directories are relevant to the user.
Directory Function
c:
config Location of Configuration files
c:\upload Location of restart.now file
c:\data or e:\data Location of recorder compressed ZIP files
d:\data Location of trend recorder files
5.5.1 FTP Server
The M87x incorporates an internet-compatible FTP (File Transfer Protocol) data server.
This allows user access to any program or data file that exists on the M87x. It has the
following primary uses:
1. Allows remote software updates to be written to the M87x.
2. Allows determination of the time of last software update.
3. Allows configuration ".INI" files to be written, copied, and deleted from the M87x.
4. Allows Comtrade files to be read and deleted from the M87x.
The M87x can support up to 50 simultaneous FTP connections.
