analysis calculations and the peak fault current. The following measurements have been
added:
Measurement Modbus DNP3
Fault Type Bus 1 Modbus register DNP Analog Input
Fault Distance XAN1 Modbus register DNP Analog Input
Fault Distance XBN1 Modbus register DNP Analog Input
Fault Distance XCN1 Modbus register DNP Analog Input
Fault Distance XAB1 Modbus register DNP Analog Input
Fault Distance XBC1 Modbus register DNP Analog Input
Fault Distance XCA1 Modbus register DNP Analog Input
Fault Type Bus 2 Modbus register DNP Analog Input
Fault Distance XAN2 Modbus register DNP Analog Input
Fault Distance XBN2 Modbus register DNP Analog Input
Fault Distance XCN2 Modbus register DNP Analog Input
Fault Distance XAB2 Modbus register DNP Analog Input
Fault Distance XBC2 Modbus register DNP Analog Input
Fault Distance XCA2 Modbus register DNP Analog Input
Peak Fault Current IA1 Modbus register DNP Analog Input
Peak Fault Current IB1 Modbus register DNP Analog Input
Peak Fault Current IC1 Modbus register DNP Analog Input
Peak Fault Current IR1 Modbus register DNP Analog Input
Peak Fault Current Bus1 Modbus register DNP Analog Input
Peak Fault Current IA2 Modbus register DNP Analog Input
Peak Fault Current IB2 Modbus register DNP Analog Input
Peak Fault Current IC2 Modbus register DNP Analog Input
Peak Fault Current IR1 Modbus register DNP Analog Input
Peak Fault Current Bus2 Modbus register DNP Analog Input
Fault Target A1 DNP Binary Output
Fault Target B1 DNP Binary Output
Fault Target C1 DNP Binary Output
Fault Completed Bus1 Modbus register DNP Binary Output
Fault Count Bus1 Modbus register DNP Analog Input
Fault Target A2 DNP Binary Output
Fault Target B2 DNP Binary Output
Fault Target C2 DNP Binary Output
Fault Completed Bus2 Modbus register DNP Binary Output
Fault Count Bus2 Modbus register DNP Analog Input
The ‘fault type’ registers are a bit-field representation of which phases were driven by the
event system, and are the same information used to generate the faulted phase strings in
the soelog. Bit0 is A, Bit1 is B, Bit2 is C. The ‘fault distance’ registers are integer
representations of the per-unit distance, in DIV1000 or DIV100 format pending exact
configuration implementation.
