will appear in grey indicating the IEC61850 IED Configurator is the active tool. Only the 70
Series Configurator allows the user to select which configurator tool loads the IP and
SNTP addresses.
The configuration files are stored in the M87x directory c:\Config. The 70 Series
Configurator will generate the IED Capability Description (ICD) file and automatically store
it on the M87x in directory c:\Config. If using IEC61850 protocol 2 additional files, an MCL
file and an MC2 file, will be generated by the IEC61850 IED Configurator and will be stored
on the M87x in the c:\Config directory. The MCL files are the Micom Configuration
Language files and contain the information pertaining to the IEC61850 Configuration. The
MCL file is stored as the active bank and contains the IEC61850 configuration and the
MC2 file becomes the inactive bank, containing the previous IEC61850 configuration.
There are also several ".BIN" files in the "c:\CONFIG\" directory which contain information
on the protocol register configuration for Modbus, Modbus Plus and DNP. These files are
written by the 70 Series Configurator and are not editable by the user.
AFTER WRITING THE CONFIGURATION FILES, THE M87X MUST BE RESET
(REBOOTED) BEFORE THE NEW CONFIGURATION WILL TAKE EFFECT.
Filename
Directory
Description
COMM.INI
c:\CONFIG\
Contains serial port information.
DEMANDS.INI
c:\CONFIG\
Contains demand intervals.
DIO.INI
c:\CONFIG\
Contains Digital I/O data, i.e. the Digital I/O debounce time.
DISPLAY.BIN
c:\CONFIG\
Contains setup information for communicating with a remote display
DNP.BIN
c:\CONFIG\
Contains DNP configurable register information
DR1.INI
c:\CONFIG\
Contains setup information for Disturbance Recorder 1
DR2.INI
c:\CONFIG\
Contains setup information for Disturbance Recorder 2
DSP.INI
c:\CONFIG\
Contains CT/VT ratios, user gains and phase, harmonic denominators,
and VA calculation types.
IDENTITY.INI
c:\CONFIG\
Contains Identity info, i.e. device name of M87x, IP address, NSAP
address.
MODBUS.BIN
c:\CONFIG\
Contains Modbus configurable register information
PROTOCOL.INI
c:\CONFIG\
Contains Modbus, Modbus Plus, and DNP protocol setup information.
SBO.INI
c:\CONFIG\
Contains UCA2.0 Select Before Operate parameters
SCALEFAC.INI
c:\CONFIG\
Contains integer-to-floating point scale factor info for UCA.
TR1.INI
c:\CONFIG\
Contains setup information for TR1 recorder.
VIO.INI
c:\CONFIG\
Contains Virtual Input/Output setting information.
WR1.INI
c:\CONFIG\
Contains Waveform Recorder 1 Configurator parameters
WR2.INI
c:\CONFIG\
Contains Waveform Recorder 2 Configurator parameters
TRIGGER.INI
c:\CONFIG\
Contains all trigger configuration info
MEASUSER.INI
c:\CONFIG\
Contains user defined measurement names
VFT.INI
c:\CONFIG\
Contains Voltage Fluctuation Table configuration
HARDWARE.INI
c:\CONFIG\
Contains configured hardware info
SYS_CNFG.INI
c:\PERSIST\
Contains hardware found by unit
