www.nvcnc.com
Chapter2 Connection
Manual of NVUM_SP
- 8 -
Pin mark Axis
Definition
COM+
Commom+ common anode +5V
CPX-
X axis Pulse output- for X axis
DIX-
X axis
Directrion output- for X axis
CPY-
Y axis
Pulse output- for Y axis
DIY-
Y axis
Directrion output- for Y axis
CPZ-
Z axis
Pulse output- for Z axis
DIZ-
Z axis
Directrion output- for Z axis
CPA-
A axis
Pulse output- for A axis
DIA-
A axis
Directrion output- for A axis
CPB-
B axis
Pulse output- for B axis
DIB-
B axis
Directrion output- for B axis
CPC-
C axis
Pulse output- for C axis
DIC-
C axis
Directrion output- for C axis
Table 2-1. Stepper driver control interface define
