Chapter1 Introduction
Manual of NVUM_SP
- 2 -
www.nvcnc.com
can support 3-6 axis stepper systems,100KHz pulse output for every axis；
ARM motion control chip；
Compatible with MPG input,support the digital display MPG from our company。
1.3 Products Appearance and size
NVUM_SPv1.1 motion controller is with the sealed shell structure,there are 4pcs setting
holes at the bottom.We can fix 4pcs 4mm diameter holes at the cabinet,and install the controller
into the cabinet.The controller appearance as the Figure 1-1 and Figure 1-2 show:
The products overall size is 96mm*62mm*20mm
；
The bottom install size is 50.3mm*81.4mm
。
Figure1-1. NVUM_SPV1.1 front appearance and size
