– 55 –
8.2.2 Replace inlet grille
Take care that the Monoblock filter and grease
filter have first been placed in the appliance
before replacing the inlet grille.
– Grasp the inlet grille and insert it in the centre of the extraction
opening in line with the position marks.
8.2.3 Cleaning the grease filter
When the grease lters need to be cleaned, this is indicated by
the grease lter cleaning indicator (see 4.5.1)
– Remove the inlet grille (see 8.2.1)
– Gr
asp the grease filter by the grips and lift it out of the
extraction opening
Wash in the dishwasher or submerge in hot water with anti-
grease dishwashing liquid.
WARNING: If the instructions above are not
carried out, serious soiling can cause a fire
hazard.
After cleaning:
– Using the grips, replace the grease filter in the right direction
in the extraction opening.
– Replace the inlet grille in the extraction opening
– Reset the grease filter indicator (see 6.1)
8.2.4 Replacing the Monoblock filter (1861 only)
– Remove the inlet grille (see 8.2.1)
– Remove the grease filter (see 8.2.3)
– Gr
asp the Monoblock filter, tilting it forwards.
– F
old both corners over and remove the Monoblock filter from
the extraction opening
After replacing:
– F
old back the corners of the new Monoblock filter and replace
it in the frame through the extraction opening
– P
ress the filter right up against the frame
– Using the grips, r
eplace the grease filter in the right direction
in the extraction opening.
– Replace the inlet grille in the e
xtraction opening
– Reset the r
ecirculation indicator (see 6.2)
