NSD VARICAM VS-5FD-1 User Manual

116
APPENDIX APPENDIX 4. DATA SHEET
(2/3)
No. Name Setting range
Applicable model
Initial
value
Setting
value
VS-5F
VS-5FD
VS-5FX
93
Timing pulse
0: 360 pulses
1: 180 pulses
2: 60 pulses
3:
Motion detection switch
Display: 360
Display: 180
Display: 60
Display: Spd
○ ○ ○ 0
92
Setting change
during operation
0: Change disable
1: Change enable
○ ○ ○ 0
91
Latch pulse cycle
Edge timing
0: 0.352 ms
1: 17.58 ms
2: 35.16 ms
Level timing
3: 1.406 ms
4: 4.219 ms
5: 8.438 ms
6: 17.58 ms
7: 35.16 ms
8: 70.32 ms
9: 140.6 ms
Display: 0.35
Display: 17.6
Display: 35.2
Display: 1.41
Display: 4.22
Display: 8.44
Display: 17.6
Display: 35.2
Display: 70.3
Display: 141
○ ○ 0
90
Switch output
enabling range
VS-5F(-1)
VS-5FD(-1)
VS-5FX(-1)
: 0 to 24
: 0 to 24
: 0 to 40
○ ○ ○ 0
89
Communication
setting
0: Setting disabled
1: Setting enabled
○ ○ ○ 0
86
Node number 0 to 15
○ ○ ○ 1
85
Protocol
0: NSD
1: MELSEC-A (Bidirectional protocol)
2: MELSEC (MC protocol)
3: OMRON
8: NDP (external display unit)
9: VARIMONI
○ ○ ○ 0
