NSD VARICAM VS-5FD-1 - Appendix 4. Data Sheet

115
APPENDIX APPENDIX 4. DATA SHEET
APPENDIX 4. DATA SHEET
APPENDIX 4-1. Parameter
(1/3)
No. Name Setting range
Applicable model
Initial
value
Setting
value
VS-5F
VS-5FD
VS-5FX
04
Contents of BCD
output connector
0: Current position value BCD
1: Speed binary code
0 to 7FF Hex (0 to 2047 r/min )
Units: 1 r/min
2: Speed binary code
0 to 7FF Hex (0 to 4094 r/min )
Units: 2 r/min
3: Gray code (720-division) of the
current position value
Updating cycle: 0.352 to 140.6ms
Latch pulse output: enable
HOLD input: enable
4: Gray code (720-division) of the
current position value (High speed)
Updating cycle: 0.176ms
Latch pulse output: disable
HOLD input: disable
○ ○ 0
03
Current position
HOLD / External
origin set selection
0: Current position HOLD
1: External origin set
○ 0
02
VS-5FX output
specifications
0: 16-program, 40-switch
1: 32-program, 24-switch
○ 0
01
ABSOCODER
rotation direction
0: CW direction Display:
1: CCW direction Display:
○ ○ ○ 0
00
Initial display
Displays “00” at first when selecting the
parameter setting (PRM) mode.
○ ○ ○ － －
99
Origin point
setting
0
○ ○ ○ 0 －
98
Current position
setting
0 to 359.5° ○ ○ ○ 0
97
Program No.
input format
0: By panel key input
1: By external connector input
2: By serial communication
○ ○ 0
96
Protected switch
0: INVALID
1: VALID
○ ○ ○ 0
95
Protected switch
cancel
0: Do not cancel
1: Cancel
○ ○ ○ 0
94
Output status in
SET mode
0: Output OFF
1: Output HOLD
○ ○ ○ 0
