SPECIFICATION 3. SPECIFICATIONS
3-1-4. Communication Interface Specification
Interface RS-232C RS-485
Communication format Full duplex, start stop synchronization Half duplex, start stop synchronization
Transmission speed 2400,4800,9600,19200,38400,57600 bps
Communication signal TXD, RXD, RTS, CTS, SG DATA+, DATA-, SG
Connector format 9-pin connector (D-sub male)
For more details about the serial communication, please contact your NSD representative.
