Disconnect the handpiece only after the motor has completely
stopped rotating.
•
CAUTION
7. Forward / Reverse Rotation
1) Forward Rotation : Turn the FWD/REV Change Ring to “F”. (Fig. 4)
2) Reverse Rotation : Turn the FWD/REV Change Ring to “R”. (Fig. 5)
3) When the FWD/REV Change Ring is positioned at the middle of “F”
and “R” , the drive air is interrupted and the motor does not rotate.
(Fig. 6)
* F : Forward Rotation
R : Reverse Rotation
8. Maintenance
After each patient maintain the product as follows.
8-1 Cleaning
1) Remove dirt and debris from the product. Do not use a wire brush.
2) Wipe clean with alcohol-immersed cotton swab or cloth.
This icon denotes that the product can be washed via Thermo
Disinfector.
(FX204m M4/FX204m B2/FX205m M4/FX205m B2)
Refer to the Thermo-Disinfector manual.
5. Check before treatment
Connect the handpiece to the motor and check for motor vibration, noise
and overheating. If any abnormalities are found do not use the motor
and contact your Authorized NSK Dealer.
6. Water and Chip Air Supply to the Handpiece
(FX205 M4/FX205m M4/FX205 B2/FX205m B2)
1) Insert the Spray Tube Attachment into the Spray Tube Nozzle.
(Fig. 3)
2) Trim the tube to the desired length.
3) Insert the other end of the Spray Tube Attachment into the nozzle
clamp on the Contra Angle or Straight handpiece.
