NSK Multi Pad User Manual

9
English
6
SETTINGS
7
USEFUL FUNCTIONS
6–1 MOTOR
)XQFWLRQV\RXFDQVHWZKLOHWKH0RWRULVURWDWLQJ0D[LPXP5RWDWLRQ6SHHG5RWDWLRQ'LUHFWLRQ
)XQFWLRQV\RXFDQVHWZKLOHWKH0RWRULVVWRSSLQJ0D[LPXP5RWDWLRQ6SHHG5RWDWLRQ'LUHFWLRQ*HDUUDWLR
PRG.
Speed setting
Press
/ key to set your desired speed at the normal display.
6SHHG5DQJHŎPLQ
-1
.
7–1 MOTOR
A maximum of 8 customized settings are available with the following selections.
Ř0D[LPXP5RWDWLRQ6SHHG
Ř5RWDWLRQ'LUHFWLRQ
Ř*HDUUDWLR
6–2 SCALER
Treatment Mode setting
Press MODE key to select the different treatments at the normal display.
“Perio”, “Endo” and “General” modes will be cycled through on every key press.
Power Level setting
Press
/ key to select the Power Level at the normal display.
key for increase, press key for decrease. (Power 0 to 10)
Gear ratio setting
A maximum of 10 different Gear ratios can be set. 8 are fixed default settings, 2 for free settings.
1) Press SELECT key until ‘Gear ratio’ on the display blinks at the normal display.
2) Press
/ key to choose an appropriate Gear ratio.
3) Press and hold ENTER/SAVE key for 3 seconds or longer to save the set Gear ratio.
Rotation Direction setting
Press FWD/REV key until “F” appears at the normal display for Motor Forward Rotation.
Press FWD/REV key until “R” appears at the normal display for Motor Reverse Rotation.
NOTICE
NOTICE
Ř Speed display changes faster as you press and hold the
/ key.
Ř The turn selected by
/ key is shown below.
*HDUUDWLRDQGDUHRQO\GLVSOD\HGZKHQ\RXVHWWKHPLQXVHUVHWWLQJPHQX
For user setting menu, refer to “9. OTHER SETTINGS”.
key key
1:5 1:4 1:2 1:1 Gear ratio
2*
Gear ratio
1*
20:1 16:1 10:1 4:1
