8-2 NBX MOTOR
The system incorporates an automatic diagnosis feature that can help to diagnose the cause of the problem
LQWKHHYHQWRIIDLOXUHPRGH:KHQWKHV\VWHPKDVIDLOHGWKHGLVSOD\ZLOOVKRZDQœ(ŎŔFRGHDQGPHVVDJH
Details of each error code are listed below.
8-3 SCALER
Error
code
Error Message Cause Solution
E–00
Over Motor current
Excessive current is applied for a given
time at high speed mode.
Remove the lead from motor/
handpiece, and release foot control.
E–01
Over PAM voltage
Error in detecting the motor voltage
more than DC28V.
Release the foot control.
E–02
PAM diff. failure
High speed Mode, Over difference
voltage of PAM control.
Release the foot control.
E–03
Over EMF voltage
Low speed Mode, Over difference
voltage of EMF control.
Release the foot control.
E–04
Torque diff. failure Over difference voltage of Torque
control.
Contact your Authorized NSK Dealer.
E–05
Input voltage error
Input voltage has exceeded the upper
and lower limit values.
Check input voltage.
E–06
Over LED voltage Detected over voltage of LED lamp. Contact your Authorized NSK Dealer.
E–07
LED diff. failure Over difference voltage of LED lamp
control.
Contact your Authorized NSK Dealer.
E–08
Over load Motor is overused. Leave the motor until it cools down.
E–09
Motor start failure Handpiece/motor cord disconnection.
Check the handpiece cord is connected
with the handpiece properly.
E–11
Air FS failure Air pressure is greater than 0.45[MPa]. Check user air pressure.
E–12
Comm. error
Disconnection or defective contact of
COM port.
Check the connection or wiring of COM
port.
E–13
Over current(endo)
Excessive current is applied for a given
time at low speed mode.
Remove the lead from motor/
handpiece, and release the foot control.
E–14
EEPROM error Memory read/write date error. Contact your Authorized NSK Dealer.
Error
code
Error Message Cause Solution
E–09
poorTool Handpiece cord disconnection.
Check the handpiece cord is connected
to the handpiece properly.
E–14
Fatal Program error. Contact your Authorized NSK Dealer.
