NSK Multi Pad User Manual

16
EMC Measurement Conditions
No. Interface(s) Max. cable length, shielding Cable classifications
1 AC input (with plug) Un–Specified AC Power Supply Line
2 AC output (CN400) 4.0m, Shielded AC Power Supply Line
3 DC power line (CN401 – CN105) 1.0m, Un–shielded DC Power Supply Line
4 Motor line (CN104 – CN500) 1.0m, Un–shielded AC Power Line
5 External I/F (CN300) 1.0m, Un–shielded Input/Output Line
6 Control line for Multi Pad (CN302) 1.0m, Un–shielded Input/Output Line
7 Lamp line (CN305 – CN501) 1.0m, Un–shielded DC Power Line
8 Motor select line (CN306 – CN502) 1.0m, Un–shielded DC Power Line
9 Motor line A (CN503) 2.2m, Un–shielded AC Power Line
10 Lamp line A (CN5040) 2.2m, Un–shielded DC Power Line
11 Motor line B (CN505) 2.2m, Un–shielded AC Power Line
12 Lamp line B (CN506) 2.2m, Un–shielded DC Power Line
Guidance and manufacturer’s declaration – electromagnetic immunity
The Multi Pad is intended for use in the electromagnetic environment specified below. The customer ot the user of the Multi Pad should assure
that it is used in such an environment.
Immunity test EN/IEC 60601 test level Compliance level Electromagnetic environment – guidance
Electrostatic discharge
(ESD)
EN 61000-4-2
IEC 61000-4-2
± 6 kV contact
± 8 kV air
± 6 kV contact
± 8 kV air
Floors should be wood, concrete or ceramic
WLOH,IƃRRUVDUHFRYHUHGZLWKV\QWKHWLF
material, the relative humidity should be at
least 30 %.
Electrical fast transient/burst
EN 61000-4-4
IEC 61000-4-4
± 2 kV for power supply lines
± 1 kV for input/output lines
± 2 kV for power supply lines
± 1 kV for input/output lines
Mains power quality should be that of a typical
commercial or hospital environment.
Surge
EN 61000-4-5
IEC 61000-4-5
± 1 kV line(s) to line(s)
± 2 kV line(s) to earth
± 1 kV line to line
± 2 kV lines to earth
Mains power quality should be that of a typical
commercial or hospital environment.
Voltage dips, short
interruptions and voltage
variations on power supply
input lines
EN 61000-4-11
IEC 61000-4-11
< 5 % Ut
(> 95 % dip in Ut) for 0.5 cycle
40 % Ut
(60 % dip in Ut) for 5 cycles
70 % Ut
(30 % dip in Ut) for 25 cycles
< 5 % Ut
(> 95 % dip in Ut) for 5 sec
< 5 % Ut
(> 95 % dip in Ut) for 0.5 cycle
40 % Ut
(60 % dip in Ut) for 5 cycles
70 % Ut
(30 % dip in Ut) for 25 cycles
< 5 % Ut
(> 95 % dip in Ut) for 5 sec
Mains power quality should be that of a
typical commercial or hospitalenvironment. If
the user of the MultiPad requires continued
operationduring power mains interruptions,
it is recommended that the Multi Pad be
powered from an uninterruptible power supply
or a battery.
Power frequency
(50 / 60 Hz) magnetic field
EN 61000-4-8
IEC 61000-4-8
3 A/m 3 A/m Power frequency magnetic fieldsshould be at
levels characteristicof a typical location in a
typicalcommercial or hospital environment.
NOTE : Ut is the a.c. mains voltage prior to application of the test level.
