NSK S-Max M15L User Manual

4
3. Connecting/ Disconnecting the Bur
(1) Connecting
a) M15L,M15,M25L,M25 (Contra Angled Bur)
1) Mount handpiece and Micromotor.
2) Insert the bur into the head and turn it slightly.(If bur and head in right position,
bur is all the way seated in the head)
3) Insert the bur into the head until it click. (Fig. 1)
b) M95L,M95 (FG bur)
1) Mount handpiece and Micromotor.
2) Depressing the pushbutton and insert the bur into the chuck. (Fig. 2, , )
3) Make sure it inserted firmly till the end of the head. Do not push the Push Button.
(Fig. 2, )
1
2
3
Fig. 2
2
3
1
M95L
D-shape
Fig. 1
M15L
