Model Z900L Z900 Z900KL Z900K Z900SL Z900BL Z900WL Z900W Z900WHL Z900MWL Z900STL
Rotation Speed 320,000 - 400,000min
-1
(at the recommended drive air pressure)
Bur Type ISO 1797-1 Ø1.59 - 1.60mm Standard Bur
Chucking Length 12mm
Max. Bur Length 21mm
Max. Working Part Diameter Ø2mm
Recommended Drive Air Pressure 0.28MPa (2.8kgf/cm
2
)
Operating Drive Air Pressure Range 0.25 - 0.30MPa (2.5 - 3.0kgf/cm
2
)
Max. Air Consumption <66NL/min (0.3MPa)
Water Pressure 0.08 - 0.20MPa (0.8 - 2.0kgf/cm
2
)
Chip Air Pressure 0.10 - 0.20MPa (1.0 - 2.0kgf/cm
2
)
Optic
Glass Rod - Glass Rod - Glass Rod White LED - Glass Rod
Voltage - AC/DC 3.3±0.05V -
Active Voltage - 2.8 - 4.0V -
Consumption Current -
0.38A Typical (3.3V)
-
Use Environment Temperature: 10 - 40°C (No Condensation), Humidity: 30 - 75%
Transportation and Store Environment Temperature: -10 - 50°C, Humidity: 10 - 85%, Atmospheric Pressure: 500 - 1,060hPa
* Available models differ according to countries/regions.
