Lx Series Installation and Operation Instructions │Trinity Lx
19
Concentric Venting Options
Figure 4-5(a) All Models (Lx200 shown) Figure 4-5(b) All Models (Lx200 shown)
Concentric Side Wall Termination (Optional Kit) Concentric Roof Termination (Optional Kit)
T
wo-Pi
p
e
V
entin
g
O
p
tions
Figure 4-6(a) Lx150-200 Figure 4-6(b) All Models
Two-Pipe Side Wall Termination Two-Pipe Roof Termination
Typical for all models.
Lx200 unit shown for
illustration purposes.
