Figure 4-17 Lx150-800
Low Profile Termination Kit
Figure 4-18 Lx300-800
Side Wall Termination Kit
Labeling and Identification – Optional Air Intake Kit
Figure 4-19 Lx500-800
Indoor Combustion Air Kit
fully assembled
and installed
Side-Wall Termination Kit
The Vent /Air-Inlet pipes are field
supplied. Major components
provided in Side-wall Kit include:
vent screen, interior trim, and
vent terminal.
Interior Trim
A
i
r
-Inlet
Piping
Vent Screen
4” Thru-Wall Extension
4” Support Couplings
Must reduce down to 4” pipe at
this point if using 6” venting
Vent terminal
mounted to
exterior wall
Framing within
wall (typical)
From
A
ppliance
To Appliance
Exhaust
Venting
Fully Assembled
and Installed
Fully Assembled
and Installed
A
i
r
-Inlet
Piping
Exhaust
Venting
A
pproved Orientation
Base
Cap
Low Profile Termination Kit
The vent /air-inlet pipes are field
supplied. Vent screens are build
in. Major components provided in
Low Profile Kit include: base, cap,
s.s. screws, and plastic anchors.
Fully Assembled
and Installed
Indoor Combustion Air Kit
Major components provided in
Kit include: MERV filter, air
intake gasket, stainless steel
housing c/w brackets, washers
Housing
Filter
Brackets
Gasket
Washers
