Lx Series Installation and Operation Instructions │Trinity Lx
39
Figure 9-1 Lx150-300 Gas Valve and Venturi Assembly
Lx150 Orientation
Figure 9-2 Lx150-300 Gas Valve and Venturi Assembly
Lx150E, Lx200 Orientation
Orifice Location
(
See Kit 82650-1
)
Gas Valve
A
ir Intake
Manifold Pressure
Test Port
Line Pressure
Test Port
Throttle/Input
A
djustment Scre
w
Venturi
Gas In
Orifice Location
(See Kit 82650-1)
Throttle/Input Adjustment
Screw
Line Pressure
Test Port
Gas In
Lx150E and Lx200
Orientation shown
Lx300 Assembly Orientation
rotated clockwise 90
o
Venturi
A
ir Intake
Manifold Pressure
Test Port
Gas Valve
