Trinity Lx │Installation and Operation Instructions Lx Series
40
Figure 9-3 Lx400 Gas Valve and Venturi Assembly
Figure 9-4 Lx500 Gas Valve and Venturi Assembly
Throttle/Input
A
djustment Screw
Venturi
A
ir Inlet
Line Pressure
Test Port
Gas In
Gas Valve
Orifice Location
(See Kit 83017-1)
Manifold Pressure
Test Port
Gas In
Gas Valve
Throttle/Input
A
djustment Screw
Manifold Pressure
Test Port
Line Pressure
Test Port
