Trinity Lx │Installation and Operation Instructions Lx Series
38
Figure 9-3 Gas Valve and Venturi Assembly (Lx400)
Figure 9-4 Gas Valve and Venturi Assembly (Lx500)
Throttle/Input
Adjustment Screw
Venturi
Air Inlet
Line Pressure
Test Port
Gas In
Gas Valve
Orifice Location
(See Kit 83017-1)
Manifold Pressure
Test Port
Gas In
Gas Valve
Throttle/Input
Adjustment Screw
Manifold Pressure
Test Port
Line Pressure
Test Port
