Trinity Lx │Installation and Operation Instructions Lx Series
Figure 9-9 Flue Gas Sampling Using Test Port (Lx500-600)
Figure 9-10 Flue Gas Sampling Using Test Port (Lx700-800)
FLUE GAS TEST PORT PLUG - Remove test
port plug to perform flue gas analysis. Re-install
plug once sampling completed to prevent flue gas
leakage during appliance operation. Failure to
comply with these instructions will result in serious
injury or death.
FLUE GAS TEST PORT PLUG
Remove test port plug to perform
flue gas analysis. Re-install plug
once sampling completed to prevent
flue gas leakage during appliance
operation. Failure to comply with
these instructions will result in
serious injury or death.
