Lx Series Installation and Operation Instructions │Trinity Lx
Figure 9-7 Flue Gas Sampling Using Test Port (Lx150-200)
Figure 9-8 Flue Gas Sampling Using Test Port (Lx300-400)
FLUE GAS TEST PORT PLUG - Remove test
port plug to perform flue gas analysis. Re-install
plug once sampling completed to prevent flue gas
leakage during appliance operation. Failure to
comply with these instructions will result in serious
injury or death.
FLUE GAS TEST PORT PLUG - Remove test
port plug to perform flue gas analysis. Re-install
plug once sampling completed to prevent flue gas
leakage during appliance operation. Failure to
comply with these instructions will result in serious
injury or death.
