Trinity Lx │Installation and Operation Instructions Lx Series
76
Item
Part #
Models
Description
30
83996
700, 800
Condensate Drain Tube (Lx700-800)
31
83112
All Models
Trinity Divider Plate Insulation c/w Washer & Screw (Lx Series)
32
82770
150–500
Burner Door Viton Gasket (Lx150-500)
32
84136
600–800
Burner Door Viton Gasket (Lx600-800)
33
83808
150, 150E, 200, 500
Burner Door Ceramic Disc (Lx150-200,500)
33
83950
300, 400
Burner Door Ceramic Disc (Lx300-400)
33
84137
600–800
Burner Door Ceramic Disc (Lx600-800)
34
83885
150, 150E, 200, 500
Cast Alum Burner Door (Lx150-200,500)
34
83949
300, 400
Cast Alum Burner Door (Lx300-400)
34
84135
600–800
Cast Alum Burner Door (Lx600-800)
35
83934
300, 400
Nipple, 1/4" x 6", Brass 113-B6 (Lx300-400)
36
82762
150–500
Flame Rod (Lx150-500)
36
84155
600–800
Flame Rod (Lx600-800)
37
82099
150, 150E, 200, 300
1-1/2" MJ Coupling (Lx150-300)
37
83951
400
2" Gear Clamp Assembly (Lx400)
38
83425
150, 150E, 200
Elbow, Street 90, PVC Sys 15,1-1/2" (Lx150-200)
39
83426-1
150 (US)
1-1/2" PVC Pipe, Sys 15, 1.75" Long (Lx150 US)
39
83426-2
150E, 200
1-1/2" PVC Pipe, Sys 15, 4.5" Long (Lx150E-200)
39(a)
84208
300
1-1/2" Air Metering Assembly (Lx300)
39(b)
84209
300
2” PVC Air Inlet Assembly (Lx300)
39
83952
400
Air Inlet Assembly (Lx400)
40
83425-1
150, 150E, 200
Air Metering Elbow (Lx150-200)
41
83712
150, 150E, 200
Flue Outlet Adapter (Trinity Lx 3” PVC), c/w plug (Lx150-200)
41
83213
300, 400
Flue Outlet Adapter (Lx300-600)
41
84387
500, 600
Flue Outlet Adapter c/w Tabs (Lx500-600)
41
84052
700, 800
Flue Outlet Adapter (Lx700-800)
42
82882
300, 400
Coupling, Rubber , 4", Fernco (Lx300-400)
42
84051
500–800
Air Inlet Adapter SS (Lx Commercial)
43
83477
150, 150E, 200
Bushing, PVC Sch. 40, 3"x1.5" (Lx150-200)
44
83712-1
150, 150E, 200
3/8" Stainless Steel Plug (Lx150-200)
44
84054
300–800
Exhaust Test Plug (Lx300-800)
45
83873
150, 150E, 200
TiS Wall Mount Bracket 2 (Lx150-200)
45
83953
300, 400
Wall Mounting Clip (Lx300-400)
46
83505
150, 150E, 200, 300
Grommet, Vinyl, 1/2" IPS (Lx150-300)
46
83923
400
Grommet, Vinyl, 3/4" IPS (Lx400)
46
83506
600–800
Grommet, Vinyl, 1" IPS (1030) (Lx600-800)
47
83506
150, 150E, 200
Grommet, Vinyl, 1-3/8" OD
47
83924
300, 400
Grommet, Vinyl, 2" OD (Lx300-400)
47
84097
500–800
Grommet, Vinyl, 2 1/2" IPS (3125) (Lx Commercial)
48
83874
150, 150E, 200
TiS Air Switch Support Clip II (Lx150-200)
48
83954
300, 400
Air Switch Bracket (Lx300-400)
48
84139
600–800
Air Switch Bracket (Lx600-800)
49
82662
All Models
Air Switch Huba 604.E021180 set @ .15" w.c. (Lx Series)
50
83875
150, 150E, 200
TiS Wall Stand-Off - Bottom (Lx150-200)
50
83955
300, 400
Wall Mounting Support, Bottom (Lx300-400)
51
83508
All Models (pre 6/1/12)
Display Molding (Models manufactured before June 1, 2012)
51
84622
All Models (post 6/1/12)
Display Molding (Models manufactured after June 1, 2012)
52
83592
200 (pre 6/1/12)
Display S7999C, White (Lx200 manufactured before June 1, 2012)
52
83592-Lx
150, 300-800 (pre 6/1/12)
Display Upgrade kit (Models manufactured before June 1, 2012)
52
84653
All Models (post 6/1/12)
Display S7999D, Black (Models manufactured after June 1, 2012)
