Lx Series Installation and Operation Instructions │Trinity Lx
75
Item
Part #
Models
Description
7
81994
300
CVI Venturi 51 (Lx300)
7
82990
400
CVI Venturi (Lx400)
7
84013
600–800
CVI Venturi (Lx600-800)
8
82650
150, 150E, 200
CVI 5.20mm Orifice #45.900.444.107B (Lx150-200)
8
84157
300
CVI 6.20mm Orifice (Lx300)
8
82993
400 (NG)
Gas Valve Orifice, 8.0mm, NG (Lx400)
8
83017
400 (LP)
Gas Valve Orifice, 6.2mm, LP (Lx400)
9
82054
150–300
Gas Valve (CVI) VK8115F1134B (Valve Only) (Lx150-300)
9
82989
400
Gas Valve VR8615VB 1044B (Lx400)
9
84318
500
Gas Valve GB-ND 057 (Lx500)
9
84012
600–800
Gas Valve V8730C 1023B (Lx600-800)
10
83870
150–500
Ignition Electrode, Dual – c/w gasket (Lx150-500)
10
84154
600–800
Ignition Electrode, Dual (Lx600-800)
11
82774
All Models
Flame Probe Gasket (Lx Series)
12
82600
150, 150E, 200, 300
Gas Valve Regulator Vent Adapter (Lx150-300)
13
83883
150, 150E, 200, 300
CVI Gas Valve Inlet O-ring Gasket (Lx150-300)
13
83194
400
Gas Valve Connector O-ring, Large (Lx400)
13
84138
600–800
Gas Valve Inlet O-ring (Lx600-800)
14
82065
150, 150E, 200, 300
Gas Valve (CV1) 1/2" NPT elbow #45.900.400-132B (Lx150-300)
14
82991
400
Gas Valve Adapter 45900400-138B, 3/4" NPT (Lx400)
14
84321
500
Gas Valve Adapter 253-517, 3/4” NPT, c/w screws and O-ring (Lx500)
14
84035
600–800
Gas Valve Adapter, 1" NPT (Lx600-800)
15
83606
All Models
Outlet Sensor, Dual (Lx Series)
16
83223-1
150, 150E, 200, 300, 400
Low Water Pressure Switch, 1/4" NPT (Lx150-400)
17
83462
150, 150E, 200
Street Tee, Brass, 1/4" (Lx150-200)
17
82698
300, 400
1/4" NPT Brass Tee (Lx300-400)
18
83007
All Models
1/4"x 1/8" Bushing Brass (Lx Series)
19
82539
All Models
Automatic Air Vent 1/8" (Lx Series)
20
83608
150, 150E, 200, 300, 400
Flue Sensor, Dual (Lx150-400)
20
84039
500–800
Flue Sensor, Dual (Lx Commercial)
21
82765
150, 150E, 200
Composite Flue Outlet Gasket (Lx150-200)
22
82763
150, 150E, 200
Composite Flue Box (Lx150-200)
23
82764
150, 150E, 200
Trinity Flue Box to Heat Exchanger Gasket (Lx150-200)
24
83605
All Models
Inlet Sensor, Single (Lx Series)
25
83706
150, 150E, 200, 300, 400
Plug, Brass, 1/4" NPT (Lx150-400)
25
84075
500–800
Plug, Brass, 1/2" NPT (Lx Commercial)
26
83395
150 (CAN)
Heat Exchanger (CAN - Lx100-150, not Lx150E) – Canada Only
26
83012
150 (US)
Heat Exchanger-ASME (US - Lx100-150, not Lx150E) – US Only
26
83396
150E, 200
Heat Exchanger-ASME (Lx150E-200)
26
84022
300
Heat Exchanger-ASME (Lx300)
26
82926
400
Heat Exchanger-ASME (Lx400)
26
84311
500
Heat Exchanger-ASME (Lx500)
26
84312
600
Heat Exchanger-ASME (Lx600)
26
84005
700, 800
Heat Exchanger-ASME (Lx700-800)
27
83042
150, 150E, 200
Y-Drain Fitting 5/8", White (Lx150-200)
28
83721
All Models
Tee, PVC, 1/2", Sch.40, White (Lx Series)
29
83720
All Models
Elbow, Street, PVC, 1/2", Sch.40, White (Lx Series)
30
83715
150, 150E, 200
Condensate Drain Tube (Lx150-200)
30
83907
300, 400
Condensate Drain Tube (Lx300-400)
30
84313
500, 600
Condensate Drain Tube (Lx500-600)
