Table 19-1 Parts List: Tx Series
Item
Part #
Description
1
84882
Burner Assembly, c/w door, insulation & gasket (Tx51)
1
84883
Burner Assembly, c/w door, insulation & gasket (Tx81)
1
84884
Burner Assembly, c/w door, insulation & gasket (Tx101)
1
84885
Burner Assembly, c/w door, insulation & gasket (Tx151 & Tx151C)
1
85056
Burner Assembly, c/w door, insulation & gasket (Tx200 & Tx200C)
2
84743
Flue Outlet Gasket (all Tx models)
3
84597
Blower Mounting Screws, M5x12 Hex (all Tx models)
4
82766
Blower Gasket (all Tx models)
5
84909
Blower/Venturi Assembly, 535 (Tx51)
5
84910
Blower/Venturi Assembly, 534 (Tx81)
5
84911
Blower/Venturi Assembly, 533 (Tx101)
5
84912
Blower/Venturi Assembly, 532 (Tx151 & Tx151C)
5
85155
Blower, RG148/1200-3612, 55667.21120A (Tx200 & Tx200C)
6
82054-2
Venturi Gasket, Cork (Tx200 & Tx200C)
7
81994
Venturi, 051 (Tx200 & Tx200C)
8
84869
LP Orifice, 3.5mm (Tx51)
8
84870
LP Orifice, 3.8mm (Tx81)
8
84871
LP Orifice, 4.2mm (Tx101)
8
84795
LP Orifice, 5.05 (Tx151 & Tx151C)
8
84157
LP Orifice, 6.2mm (Tx200 & Tx200C)
9
84713
Gas Valve (Tx51-151 & Tx151C)
9
85002
Gas Valve, VK4115 (Tx200 & Tx200C)
10
84738-1
Ignition Electrode, c/w gasket & cable (all Tx models), gap = 3/16 to 1/4 inch
11
84739
Ignition Electrode Gasket
12
84914
Brazed Plate Heat Exchanger (Tx151C & Tx200C)
14
84763
Gas Valve Adapter, c/w screws and O-ring (Tx51-151 & Tx151C)
14
82065
Gas Valve Adapter, c/w screws and O-ring (Tx200 & Tx200C)
15
84781
Outlet Sensor, clip-on, c/w retaining clip (all Tx models)
16
84733 (old)
O-ring (small), Boiler Inlet/Outlet, 2.76 x 17.72 (Tx51 – pre s/n 72000)
16
84735 (old)
O-ring (medium), Boiler Inlet/Outlet, 3.2 x 19 (Tx81-151 & Tx151C – pre s/n 72000)
16
84976
O-ring, Boiler Inlet/Outlet (all Tx models post s/n 72000)
17
84732 (old)
Retaining Clip – Boiler Outlet/Inlet Pipe, 18mm (Tx51 – pre s/n 72000)
17
84734 (old)
Retaining Clip – Boiler Outlet/Inlet Pipe, 19mm (Tx81-151, Tx151C – pre s/n 72000)
17
84975
Retaining Clip – Boiler Outlet/Inlet Pipe, 25mm (all Tx models post s/n 72000)
18
84809 (old)
Outlet Pipe, 18mm (Tx51 – pre s/n 72000)
18
84806 (old)
Outlet Pipe, 19mm (Tx81-151 – pre s/n 72000)
18
84972
Outlet Pipe, 25mm (Tx51-200 – post s/n 72000)
18
84804 (old)
Outlet Pipe, Combi, 19mm (Tx151C – pre s/n 72000)
18
84970
Outlet Pipe, Combi, 25mm (Tx151C – post s/n 72000)
18
84998
Outlet Pipe, Combi, 25mm (Tx200C)
19
84474
Auto Air Vent, ½” NPT (all Tx models)
20
84780
Flue Sensor (all Tx models)
21
84810 (old)
Inlet Pipe, 18mm (Tx51 – pre s/n 72000)
21
84974
Inlet Pipe, 25mm (Tx51 & Tx200 – post s/n 72000)
21
84807 (old)
Inlet Pipe, 19mm (Tx81-151 – pre s/n 72000)
21
84973
Inlet Pipe, 25mm (Tx81-151 – post s/n 72000)
21
84805 (old)
Inlet Pipe, Combi, 19mm (Tx151C – pre s/n 72000)
21
84971
Inlet Pipe, Combi, 25mm (Tx151C – post s/n 72000)
21
84999
Inlet Pipe, Combi, 25mm (Tx200C)
22
84801
Auto Air Vent Adapter (all Tx models)
