Tx I&O Manual │ Parts List
79
Item
Part #
Description
23
84423
Receptacle, 120VAC (all Tx models)
24
84745
Inlet/Pressure Sensor (all Tx models)
25
84913
Sight Glass, c/w gasket (all Tx models)
26
84673 (old)
Heat Exchanger, ASME 2+1 (Tx51 – pre s/n 72000)
26
85022
Heat Exchanger, ASME 2+1 (Tx51 – post s/n 72000)
26
84674 (old)
Heat Exchanger, ASME 3+1 (Tx81 – pre s/n 72000)
26
85023
Heat Exchanger, ASME 3+1 (Tx81 – post s/n 72000)
26
84675 (old)
Heat Exchanger, ASME 4+1 (Tx101 – pre s/n 72000)
26
85024
Heat Exchanger, ASME 4+1 (Tx101 – post s/n 72000)
26
84676 (old)
Heat Exchanger, ASME 5+1 (Tx151 & Tx151C – pre s/n 72000)
26
85025
Heat Exchanger, ASME 5+1 (Tx151 & Tx151C – post s/n 72000)
26
85026
Heat Exchanger, ASME 7+2 (Tx200 & Tx200C)
27
83044-1
Condensate Drain Tube, 17”, c/w retaining nut & gear clamps (all Tx models)
29
84915
Diverter Valve Stepper Motor (Tx151C & Tx200C)
30
83510
Condensate Trap Assembly (all Tx models)
31
84742
Deflector Insulation (all Tx models)
32
84737
Burner Door Gasket, EPDM (all Tx models)
33
84736
Burner Door Ceramic Insulation (all Tx models)
35
84214
Grommet, Diaphragm, ½” (all Tx models)
36
84740-1
Ionization Electrode, c/w gasket & cable (all Tx models)
37
84755
MJ Coupling, 1-1/2 x 1-1/4 (Tx51-151 & Tx151C)
37
82099
MJ Coupling, 1-1/2 (Tx200 & Tx200C)
38
82615
2” Bird Screen (Tx51-151 & Tx151C)
39
84881
Air Inlet Assembly (Tx51-151 & Tx151C)
39
85121
Air Inlet Assembly (Tx200 & Tx200C)
41
85132
Flue Outlet Adapter, c/w test plug (all Tx models)
42
85133
Air Inlet Adapter (all Tx models)
45
84920
Wall Mount Bracket, Top (all Tx models)
46
83505
Gas Line Grommet, ½” IPS (all Tx models)
47
84917
Circulator Cartridge, UPS15-78 (Tx151C & Tx200C)
48
84886
Thermal Fuse (all Tx models) – IF OPEN, REPLACE HEAT EXCHANGER!!!
49
84440
Air Vent Grommet, 1875 (all Tx models)
50
84872
Wall Mount Bracket, Bottom (all Tx models)
52
84764-1
Display Assembly, 210LB (all Tx models)
56
83707
Spark Ignition Transformer (all Tx models – post s/n 72170)
57
83724
Spark Igniter Wire (all Tx models – post s/n 72170)
58
84803
Pressure Sensor Retaining Clip (all Tx models)
59
82759
Tee, Brass, 1 x 1 x 3/4" (Tx51-200)
59
84978
Relief Valve Manifold (Tx151C & Tx200C – post s/n 72000)
61
84712
Controller, 210MN (all Tx models)
63
Tx Wiring Harness
Wiring Harness Complete (all Tx models)
67
84918
Fuse, LFT 3.15A, 250V (all Tx models)
70
Control Panel Sheet Metal (all Tx models)
71
83604
Outdoor Sensor, 10K (all Tx models)
72
Front Cover (all Tx models)
73
Right Side (Tx51-151 & Tx151C)
73
Right Side (Tx200 & Tx200C)
74
Left Side (Tx51-151 & Tx151C)
74
Left Side (Tx200 & Tx200C)
75
Top (Tx51)
