K. Technical Specifications
Model TRX085 TRX120 TRX110C TRX150C
Type Boiler Combi
Installation Indoor, Wall Hung, Fully Condensing
Space Heating
Minimum / Maximum Input (Btu/Hr)
1
9,400 / 85,000 13,200 / 120,000 11,200 / 106,000 13,200 / 120,000
Domestic Hot Water
Minimum / Maximum Input (Btu/Hr)
1
N/A N/A 11,200 / 114,000 13,200 / 150,000
DOE AFUE
2
(%) 96 95 95.5 95
Heating Capacity
1, 2
(MBH) 79 111 98 111
Net AHRI Rating, Water (MBH)
2
69 97 85 97
Hot Water Capacity
35
o
F Rise N/A N/A 6.0 7.9
45
o
F Rise N/A N/A 4.7 6.1
77
o
F Rise N/A N/A 2.7 3.6
Flue System Category IV, Sealed Combustion Direct Vent, Power Vent
Minimum - Maximum Exhaust Vent Run
3
2” (6 - 100 feet), 3” (6 - 150 feet)
Minimum - Maximum Intake Air Pipe Run
3
2” (0 - 100 feet), 3” (0 - 150 feet)
Approved Exhaust Vent Materials
3
PVC, CPVC, PP, Stainless Steel
Shipping Weight (lbs) 78 84 83 84
Gas Supply
Pressure
NG 3.5” to 10.5” WC
LP 8” to 13” WC
Power Supply 120V, 60 Hz, less than 12A
General Operating Conditions
Ambient Temperature Range: 33 – 104
o
F (0.6 – 40
o
C)
Product Approvals and Requirements: ANSI Z21.13 / CSA 4.9
Ignition System Direct Electronic Spark Ignition / Flame Rectification
Burner System Premixed Fuel Modulation / Stainless Steel Burner
Gas Valve System Air Ratio Valve
Dimensions
(in Inches)
W 16” 3/64
H 43” 5/8
D 15” 1/8
Approx. Full Boiler Weight (lbs) 88.2 88.6 91 92.8
Boiler Water Content (Gallons) 1.1 1.2 1.1 1.2
Boiler Setpoint Temperature Range 68 – 122
o
F Low Temperature / 86 - 179
o
F High Temperature
DHW Indirect Setpoint Temperature Range 104 – 149
o
F
DHW Setpoint Range (Combi Models) 97 – 140
o
F
Water Pressure (PSI)
Heat Exchanger MAWP 55
Pressure Relief Valve 30
DHW Max Pressure N/A N/A 150 150
Control Panel / Main Controller AristonThermo LCD Display / AristonThermo GALEVO2 Control
Connection
Sizes
CH Supply / Return 1” Male Sweat with Adapter
DHW Inlet / Outlet 3/4” Male Sweat with Adapter
Gas Inlet 3/4” Male NPT
Materials
Cabinet Painted Steel and Plastic
Heat Exchanger Type 441 Stainless Steel Water Tube
Safety Devices
Flame Rectifier Probe, Temperature Limit Control (190
o
F), Water Pressure Switch (Min. 8 PSI), Freeze
Protection, Blocked Condensate Pressure Switch, Condensate Trap, Flue Temperature High Limit Sensor
(210
o
F), Blocked Vent Pressure Switch
NOTES:
1
Listed Input and Output Ratings are at minimum vent lengths at an altitude of 0 - 2000 ft. Numbers will be lower with longer venting and/or altitudes
greater than 2000 ft.
2
Ratings based on standard test procedures prescribed by the US Department of Energy.
3
The TRX requires a special venting system. Use only the vent materials and methods detailed in these installation instructions.
Part 3 - Prepare the Boiler for Installation
Table 8 - Technical Specifications
