40
420012001500 - 03182024 - Rev. 04
3. Insert the air intake pipe until it touches the bottom of the fitting.
4. Tighten the gear clamp using a screwdriver. See Figure 33.
2. If using the right side connection, remove the gear clamp from the
left side connection and install it on the right side. See Figure 33.
You must cut out the plastic on the air intake connection being used
before installing the air intake pipe. Failure to do so will result in
improper boiler operation, property damage, severe personal injury,
or death.
WARNING
Figure 34 - Air Intake Pipe Installed (Left Side Installation Demonstrated)
Part 5 - Venting
Figure 33 - Remove the Clamp
