RM/RA SERIES OWNER'S MANUAL
NUVU® MENOMINEE, MICHIGAN 49858
page 10 SALES FAX (906) 863-5889 • SERVICE FAX (906) 863-6322 (906) 863-4401
The oven should be connected according to all national and local electrical codes, either through a
plug-type connection or direct wiring. All connections must be made with COPPER WIRE ONLY
in the correct gauge for the application. Provide enough slack in the wiring to allow for equipment
to be moved about during installation and any future required servicing.
The following steps should be carefully observed (refer to Illustration #2 above):
A. Take note of the labeling on the terminal connections (Line 1, Line 2, Line 3, Neutral) at
the Power Terminal Block.
B. Carefully identify the power source connections and attach them to the appropriate
terminals. Make sure all connections are clean and tight.
C. . Be sure the unit is properly grounded BEFORE USE by attaching a grounding wire to
the Ground Lug next to the Power Terminal Block.
D. Carefully set all Switches and Controls on the unit to the OFF position and engage the
main power supply.
E. Check the voltage at the connections on the Power Terminal Block with a voltmeter to
confirm conformity with the unit label requirements. If all readings are correct the unit is
ready for its INITIAL START–UP. If the readings DO NOT coincide with the unit
requirements you must call the NU–VU® Service Department.
F. Replace the Top Panel on the unit. Be careful not to pull or pinch any wires while
installing the panel.
G. Complete the installation of the optional water supply to the unit (refer to
INSTALLATION OF WATER SUPPLY immediately following).
H. Push the unit back into place. Make sure the unit is level and solid.
INSTALLATION OF WATER SUPPLY:
IMPORTANT: NUVU® strongly recommends that SOFT WATER ONLY be used in any unit
requiring a water supply. Also, a good quality water filter MUST be installed in-line between the
unit connection and the water supply to guard against clogging and mineral build-up in the
components. This is extremely important in areas having hard water. The water filter may be
installed at the water source or adjacent to the Water Inlet Fitting on the rear or side of the unit,
whichever is more convenient for you.
This equipment is to be installed to comply with the applicable federal, state and local plumbing
codes having jurisdiction.
Please follow these steps to connect a water supply to your unit:
A. Run ¼" tubing from the water supply line to the unit location. Allow some slack for final
IMPORTANT: IN ANY 240-VOLT THREE PHASE SYSTEM THE WILD LEG
(240 VOLTS TO NEUTRAL) MUST ALWAYS BE CONNECTED TO L-2!!!
IMPORTANT: FAILURE TO FOLLOW THESE INSTRUCTIONS OR
IMPROPER INSTALLATION MAY CAUSE SEVERE EQUIPMENT DAMAGE
OR EVEN PERSONAL INJURY, AND MAY ALSO VOID ALL OR PART OF
YOUR TOASTMASTER® EQUIPMENT WARRANTY!!!
