9
27. 10. 20. Document Number 671590Nuaire | Western Industrial Estate | Caerphilly | CF83 1NA | nuaire.co.uk
AVT-(R/X)
Installation Manual
10.0 AFTER SALES AND REPLACEMENT PARTS
For technical assistance or further product information, including spare
parts and replacement components, please contact the After Sales
Department.
If ordering spares please quote the serial number of the unit together
with the part number, if the part number is not known please give a full
description of the part required. The serial number will be found on the
identification plate attached to the unit casing.
10.1 Replacing Fan / Motor
The only items of the fan units unit likely to require replacement are
the fan/motor assemblies due to a failed motor or damaged impeller or
damper actuator.
Remove the access cover. Disconnect the incoming wiring from the
connection box (located on the fan scroll) on the particular fan/motor
assembly to be removed.
Remove the fan/motor fixings completely, other than the two slotted
hole fixings. Support the fan/motor assembly and loosen the slotted
hole fixings. The fan/motor assembly can now be turned and withdrawn
from the unit.
After replacing the faulty item, refit the fan motor/assembly using the
slotted hole fixings to assist in supporting the assembly. Re-connect the
wiring. Replace the access cover.
Telephone 02920 858 400
