MEGAWATT CARBON BIKE MANUAL | 2 0
HOW TO REMOVE AND FIT THE MEGAWATT CARBON BATTERY
The Megawatt Carbon’s internal battery can be easily removed. This process is outlined in the images below.
1. To remove or install the battery you will need 5mm Hex
Key and a torque wrench.
2. If you do not have a work stand lay the bike on the floor
drive side up.
3. First remove the reverse-threaded battery door cap
(turn clockwise to remove).
4. Remove the battery door by sliding it downwards and
pulling toward the rear of the bike. Set it aside.
5. Unplug the cable from the battery. The cable is secured
by magnets and simply pulls apart.
6. While holding the battery in the frame, use a 5mm Hex
Key to remove the battery bolt (anti-clockwise).
